Features:
1. Waterproof (IP68) and oil-sealed, work underwater up to 50m (200m optional).
2. Compact, rust-proof chassis fits small spaces.
3. Rubber tracks provide strong grip and stability.
4. High-pressure drive with cable control up to 600m, with optional automatic cable winder.
5. Optional: One or four-channel remote control.
6. Optional: IP68 underwater camera for visual tasks.
7. Supports tools like mud pumps, cutters, water guns, and robotic arms.
| Item |
Data |
Item |
Data |
| Dimension |
625*410*230mm |
Speed |
2KM/h |
| Motor power |
DC48V |
Motor |
200W*2 |
| Self Weight |
20kg |
Designed Load |
30kg |
| Waterproof |
IP68 |
Rated Torque |
35NM |
| Drive wheel diameter |
95mm |
Maximum Track span |
160mm |
| Track Width |
80mm |
Maximum Underwater Depth |
50m |
| Gear Ratio |
1:30 |
Climbing Ability |
≤30°(can climb stairs) |
| Motor Rated Speed |
3000r/min |
Cable Control Distance |
Standard 50m, maximum 600m |
| Track grounding length |
485mm |
Obstacle crossing ability |
65mm |
