Advantages:
1. Oil-sealed motor, designed for underwater up to 30m.
2. Tracks adjust to fit round pipes, offering a strong grip for both square and round pipes.
3. Front tools like a mud pump, cutter, and water gun could be added to clean plant roots and debris at pipe junctions.
4. High-voltage drive with a control range of 50 meters (standard) to max 600 meters.
5. Optional remote control.
6. Optional underwater camera (IP68) for visual guidance.
7. Multiple power system options: Battery (200AH), generator, or 380V AC power.
| Item |
Parameter |
Item |
Parameter |
| Dimension |
1100*710*420mm |
Drive wheel diameter |
260mm |
| Motor power |
3Kw*2 |
Speed |
4km/h |
| Track width |
150mm |
Maximum track span |
260mm |
| Control mode |
Cable control |
Weight |
210Kg |
| Reduction ratio |
15 |
Output torque |
400NM |
| Waterproof grade |
IP68 (50m， 150m, can be customized for 300m depth underwater) |
Cable length |
50m
(Can customize 600m) |
| Track grounding length |
800mm |
Obstacle crossing ability |
150mm |
