| Specific of Vehicle | |
| Dimension | 1150*638*400mm |
| Wheel track | 556mm |
| Wheel base | 500mm |
| Tire specifications | 3.0-8, tire diameter 350mm |
| Minimum ground clearance | 91mm |
| Weight | 98kg |
| Rated load | 200kg |
| Chassis performance | |
| Drive mode | Front Ackerman steering, rear hub motor drive |
| Brake mode | Hydraulic holding brake, anti-cracking brake |
| Front and rear suspension mode | Hidden spring shock |
| Speed | ≤5km/h(10km/h adjustable) |
| Endurance | 45km |
| Braking distance | 0.3m |
| Turning radius | 1.5m |
| Max. Climbing | 20° |
| Obstacle clearance height | 55mm |
| Security | Touch stop bar, emergency brake button (can also customize lidar shock absorber) |
| Electric Drive | |
| Motor type | Wheel hub motor, permanent Magnet Synchronous Motor |
| Motor power | 450w*2 |
| Battery parameter | 48/20v/ah |
| Charger | Ac220v |
| Charging time | Less than 6 hours, fast charging customizable |
| External power supply | 12v/48v |
| Protection class | IP35, IP66 customizable |
| Others | |
| Communication Interface | Open the underlying CAN protocol |
| Sport control | VCU control |
| Sensor type | Steering feedback sensor Walking wheel speed sensor Front and rear brake feedback sensors |
